Traditional Espresso Machine

CLASSE 11 USB Xcelsius

Groupheads
Version Automatic
Version Automatic
Version Automatic
Colors
Colors
Colors

Technical specifications

  • Standard
  • Optional
Dimensions
  • 800 mm / 31.5 inch
  • 540 mm / 21.2 inch
  • 600 mm / 23.6 inch
  • 82 kg / 180.8 lb
  • Yes
  • 80 mm / 3 inch
Interface
  • Touchscreen 5.7
  • Grouphead display
Brewing technology
  • Multi-boiler system
  • Plug and Brew

    Thanks to the Plug&Brew function, dosages and main functions are preloaded by default upon installation and ready to use.

  • Standard Quality Espresso

    By activating the SQE function, baristas can keep the time of each extraction under control to guarantee the same quality in every cup.

  • Temperature Profiling

    Temperature Profiling is a technology designed to enhance the sensory properties of any coffee, dynamically adjusting the water temperature during the 25-30 second brewing process: by increasing or decreasing this temperature by up to 5°C (9°F), specific characteristics of the espresso can be changed to achieve significant improvements in the quality of the quality of the product in the cup.
    Rancilio patented technology

  • Brass
Water
  • Hot water wand
  • X-Tea

    Baristas can program water dosages and temperature levels via the digital touchscreen interface.
    Rancilio patented technology

Steam
  • C-lever

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. By turning it downwards, the valve opens and automatically closes when released.

  • Cool touch steam wand

    The cool touch steam wand is thermally insulated with a double protective coating.

  • iSteam

    The iSteam wand features two buttons: “Cappuccino” to heat and froth milk, or “Latte” to heat only.
    Rancilio patented technology

Cup warmer
  • Cup warmer
  • Sensor
Power
  • 4300 W
  • 50/60 Hz
  • 220-240/380-415 (3N) V
Boiler
  • 11 liter / 2.4 UK gal
Design
  • Led lights

    LED lights on work area and for Classe 20 SB also on control panel, side panels.

  • RGB lights

    RGB lights on group covers, control panel, side panels.

Green
  • ABM

    The ABM (Advanced Boiler Management) is a specific software developed to improve the performance of the machine in intense use conditions. When simultaneously brewing espresso, dispensing water and steaming milk, ABM switches on the heating element to pre-empt any drops in temperature and ensure constant heating levels. ABM also allows control of the machine’s power absorption, reducing it to 2/3 of the normal value where power availability is low.

  • Eco Mode
    • Insulated boiler and smart energy management save up to 20% of energy in standby mode. By managing different water levels in the boiler, the water-to-steam ratio can be optimised to achieve great brewing performance in heavy load conditions (Performance Mode) or maximum savings in low usage conditions (Eco Mode).
Cleaning & maintenance
  • Easy clean

    Easy Clean provides smart management of the brewing unit cleaning process, making it completely automatic and allow to programme 3 automatic daily cleaning cycles, set the optional machine stop if cleaning has not been carried out and view the cleaning cycle history.

  • Grid System

    The removable cup tray grids are made of scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.

  • Hydro Hub

    The Hydro Hub is an innovative system for the comprehensive and integrated management of the machine’s hydraulic circuit. The Hydro Hub acts as a circuit board for the water delivery system, simplifying water flow and reducing connection points. This innovative solution eases technical operations while ensuring maximum safety during maintenance.

  • Snap&Share

    Snap&Share is a QR Code reader app that allows users to share technical parameters, track maintenance operations, monitor consumption and register a new product to activate the warranty.

  • USB
  • V-Flex

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. By turning it downwards, the valve opens and automatically closes when released.

Additional Optionals
  • Connect

    Connect is a remote telemetry system to monitor all the operations performed by a single coffee machine or by a whole set of machines. Thanks to Connect, you can adjust the settings for coffee delivery, analyse consumption statistics and read any messages related to technical assistance and maintenance.

  • Pods&Caps
Dimensions
  • 1040 mm / 40.9 inch
  • 540 mm / 21.2 inch
  • 600 mm / 23.6 inch
  • 103 kg / 227.1 lb
  • Yes
  • 80 mm / 3 inch
Interface
  • Touchscreen 5.7
  • Grouphead display
Brewing technology
  • Multi-boiler system
  • Plug and Brew

    Thanks to the Plug&Brew function, dosages and main functions are preloaded by default upon installation and ready to use.

  • Standard Quality Espresso

    By activating the SQE function, baristas can keep the time of each extraction under control to guarantee the same quality in every cup.

  • Temperature Profiling

    Temperature Profiling is a technology designed to enhance the sensory properties of any coffee, dynamically adjusting the water temperature during the 25-30 second brewing process: by increasing or decreasing this temperature by up to 5°C (9°F), specific characteristics of the espresso can be changed to achieve significant improvements in the quality of the quality of the product in the cup.
    Rancilio patented technology

  • Brass
Water
  • Hot water wand
  • X-Tea

    Baristas can program water dosages and temperature levels via the digital touchscreen interface.
    Rancilio patented technology

Steam
  • C-lever

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. By turning it downwards, the valve opens and automatically closes when released.

  • Cool touch steam wand

    The cool touch steam wand is thermally insulated with a double protective coating.

  • iSteam

    The iSteam wand features two buttons: “Cappuccino” to heat and froth milk, or “Latte” to heat only.
    Rancilio patented technology

Cup warmer
  • Cup warmer
  • Sensor
Power
  • 5400 W
  • 50/60 Hz
  • 220-240/380-415 (3N) V
Boiler
  • 16 liter / 3.5 UK gal
Design
  • Led lights

    LED lights on work area and for Classe 20 SB also on control panel, side panels.

  • RGB lights

    RGB lights on group covers, control panel, side panels.

Green
  • ABM

    The ABM (Advanced Boiler Management) is a specific software developed to improve the performance of the machine in intense use conditions. When simultaneously brewing espresso, dispensing water and steaming milk, ABM switches on the heating element to pre-empt any drops in temperature and ensure constant heating levels. ABM also allows control of the machine’s power absorption, reducing it to 2/3 of the normal value where power availability is low.

  • Eco Mode
    • Insulated boiler and smart energy management save up to 20% of energy in standby mode. By managing different water levels in the boiler, the water-to-steam ratio can be optimised to achieve great brewing performance in heavy load conditions (Performance Mode) or maximum savings in low usage conditions (Eco Mode).
Cleaning & maintenance
  • Easy clean

    Easy Clean provides smart management of the brewing unit cleaning process, making it completely automatic and allow to programme 3 automatic daily cleaning cycles, set the optional machine stop if cleaning has not been carried out and view the cleaning cycle history.

  • Grid System

    The removable cup tray grids are made of scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.

  • Hydro Hub

    The Hydro Hub is an innovative system for the comprehensive and integrated management of the machine’s hydraulic circuit. The Hydro Hub acts as a circuit board for the water delivery system, simplifying water flow and reducing connection points. This innovative solution eases technical operations while ensuring maximum safety during maintenance.

  • Snap&Share

    Snap&Share is a QR Code reader app that allows users to share technical parameters, track maintenance operations, monitor consumption and register a new product to activate the warranty.

  • USB
  • V-Flex

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. By turning it downwards, the valve opens and automatically closes when released.

Additional Optionals
  • Connect

    Connect is a remote telemetry system to monitor all the operations performed by a single coffee machine or by a whole set of machines. Thanks to Connect, you can adjust the settings for coffee delivery, analyse consumption statistics and read any messages related to technical assistance and maintenance.

  • Pods&Caps
Dimensions
  • 1280 mm / 50.4 inch
  • 540 mm / 21.2 inch
  • 600 mm / 23.6 inch
  • 116 kg / 255.7 lb
  • Yes
  • 80 mm / 3 inch
Interface
  • Touchscreen 5.7
  • Grouphead display
Brewing technology
  • Multi-boiler system
  • Plug and Brew

    Thanks to the Plug&Brew function, dosages and main functions are preloaded by default upon installation and ready to use.

  • Standard Quality Espresso

    By activating the SQE function, baristas can keep the time of each extraction under control to guarantee the same quality in every cup.

  • Temperature Profiling

    Temperature Profiling is a technology designed to enhance the sensory properties of any coffee, dynamically adjusting the water temperature during the 25-30 second brewing process: by increasing or decreasing this temperature by up to 5°C (9°F), specific characteristics of the espresso can be changed to achieve significant improvements in the quality of the quality of the product in the cup.
    Rancilio patented technology

  • Brass
Water
  • Hot water wand
  • X-Tea

    Baristas can program water dosages and temperature levels via the digital touchscreen interface.
    Rancilio patented technology

Steam
  • C-lever

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. By turning it downwards, the valve opens and automatically closes when released.

  • Cool touch steam wand

    The cool touch steam wand is thermally insulated with a double protective coating.

  • iSteam

    The iSteam wand features two buttons: “Cappuccino” to heat and froth milk, or “Latte” to heat only.
    Rancilio patented technology

Cup warmer
  • Cup warmer
  • Sensor
Power
  • 5400 W
  • 50/60 Hz
  • 220-240/380-415 (3N) V
Boiler
  • 22 liter / 4.8 UK gal
Design
  • Led lights

    LED lights on work area and for Classe 20 SB also on control panel, side panels.

  • RGB lights

    RGB lights on group covers, control panel, side panels.

Green
  • ABM

    The ABM (Advanced Boiler Management) is a specific software developed to improve the performance of the machine in intense use conditions. When simultaneously brewing espresso, dispensing water and steaming milk, ABM switches on the heating element to pre-empt any drops in temperature and ensure constant heating levels. ABM also allows control of the machine’s power absorption, reducing it to 2/3 of the normal value where power availability is low.

  • Eco Mode
    • Insulated boiler and smart energy management save up to 20% of energy in standby mode. By managing different water levels in the boiler, the water-to-steam ratio can be optimised to achieve great brewing performance in heavy load conditions (Performance Mode) or maximum savings in low usage conditions (Eco Mode).
Cleaning & maintenance
  • Easy clean

    Easy Clean provides smart management of the brewing unit cleaning process, making it completely automatic and allow to programme 3 automatic daily cleaning cycles, set the optional machine stop if cleaning has not been carried out and view the cleaning cycle history.

  • Grid System

    The removable cup tray grids are made of scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.

  • Hydro Hub

    The Hydro Hub is an innovative system for the comprehensive and integrated management of the machine’s hydraulic circuit. The Hydro Hub acts as a circuit board for the water delivery system, simplifying water flow and reducing connection points. This innovative solution eases technical operations while ensuring maximum safety during maintenance.

  • Snap&Share

    Snap&Share is a QR Code reader app that allows users to share technical parameters, track maintenance operations, monitor consumption and register a new product to activate the warranty.

  • USB
  • V-Flex

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. By turning it downwards, the valve opens and automatically closes when released.

Additional Optionals
  • Connect

    Connect is a remote telemetry system to monitor all the operations performed by a single coffee machine or by a whole set of machines. Thanks to Connect, you can adjust the settings for coffee delivery, analyse consumption statistics and read any messages related to technical assistance and maintenance.

  • Pods&Caps
