Traditional Espresso Machines

Classe 11 USB

Single-boiler espresso machine available in 2, 3 or 4 groups with automatic dosing (USB) and Steady Brew technology (SB).

Groupheads
Version Automatic
Version Automatic
Version Automatic
Colors
  • Anthracite black
  • Froozen bronze
  • Ice White
Colors
  • Anthracite black
  • Froozen bronze
  • Ice White
Colors
  • Anthracite black
  • Froozen bronze
  • Ice White

Technical specifications

  • Standard
  • Optional
Dimensions
  • 800 mm / 31.5 inch
  • 540 mm / 21.2 inch
  • 600 mm / 23.6 inch
  • 85 kg / 187.4 lb
  • Yes
  • 80 mm / 3 inch
Interface
  • Touchscreen 5.7
  • Grouphead display
Brewing technology
  • Steady Brew (SB)

    Rancilio Steady Brew (SB) technology is the evolution of the traditional thermosiphon system and introduces a set of innovative features designed to improve the performance of all single-boiler espresso machines. By keeping the water temperature stable during extraction, Steady Brew guarantees excellent thermal stability, reliability and maximum repeatability, both during busy periods and in low usage conditions. Rancilio Patented Technology.

  • Brass
Water
  • Hot water wand
  • X-Tea

    Baristas can programme water dosages and temperature levels via the interface.
    Rancilio Patented Technology

Steam
  • C-lever

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. Turning it downwards, the valve opens and automatically closes when released.

  • Cool touch steam wand

    The cool touch steam wand is thermally insulated with a double-layered protective coating.

  • iSteam

    The iSteam automatic steam wand features two buttons, both of which can be programmed with the following functions: “Cappuccino”, to heat and froth milk, or “Latte”, to heat only. Rancilio Patented Technology.

Cup warmer
  • Cup warmer

    The cup warmer keeps all espresso and cappuccino cups at the right temperature at all times.

  • Temperature sensor
Power
  • 4300 W
  • 50-60 Hz
  • 220-240/380-415 (3N) V
Boiler
  • 11 liter / 2.4 UK gal
Design
  • Led lights

    White LED lights positioned under the group heads provide excellent illumination for the work area.

  • RGB lights

    The aesthetic RGB lights can be customised with different intensities and colours (Classe 20 only). The functional RGB lights on the group covers (Classe 11, Classe 7 USB) and above the control panel (Classe 9) help the operator to monitor the various states of the machine at a glance.

Green
  • ABM

    ABM is a specific software developed to improve the performance of the machine in conditions of intensive use. When simultaneously brewing espresso, dispensing water and steaming milk, ABM switches on the heating element to pre-empt any drops in pressure under the preset value, thus preventing drops in temperature to ensure constant heating levels.
    Control of the boiler pressure is optimised in the case of the intensive and simultaneous use of multiple group heads. In these cases, in order to prevent the pressure from dropping below a minimum value of 0.5 bar, ABM can stop water from being dispensed until the boiler pressure returns to a suitable level.
    ABM also allows for control of the machine’s power consumption, reducing it to 2/3 of the normal value where power availability is low.
    For espresso machines equipped with the iSteam wand, ABM also improves steam delivery performance by increasing the power of the heating element in the boiler, allowing it to produce more heat and reduce drops in pressure during milk frothing.
    Rancilio Patented Technology

  • Eco Mode

    By managing the different water levels in the boiler, the water-to-steam ratio can be optimised to achieve maximum energy savings. In low usage conditions, the quantity of water in the boiler is reduced, thus increasing the proportion of steam. Working with less water in the boiler allows for lower energy consumption in order to bring it to the ideal temperature. And, at the same time, with more steam and less moisture in the boiler, the performance of the steam wands also improves.

Cleaning & maintenance
  • Easy clean

    Easy Clean manages the cleaning process of the group heads, so it can perform it all automatically. The barista need only start the cycle, and the machine will automatically carry out the washing and rinsing operations. For all models (except the Classe 5 units), Easy Clean also allows you to schedule a daily alarm (3 alarms for the Classe 11 and Classe 20 models) to warn the user of the need for a cleaning cycle, set an optional block on the machine in the event of a cleaning cycle, and view the history of all cleaning cycles performed.

  • Grid System

    The removable cup tray grids are made of a scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.

  • Snap&Share

    Snap&Share is a QR code reader app that allows users to share the technical settings of their espresso machine, keep track of maintenance operations, monitor consumption, and register new products to activate the warranty.

  • USB
Additional Optionals
  • Connect

    Connect is a powerful IoT solution developed by Rancilio Group, to gather and easy analyze all the value relevant data generated by a single coffee machine or an entire fleet. Via a customizable dashboard with widgets, tables and graphs, Connect gives you a ready to use digital toolkit, to monitor key performance parameters in real time and empower your whole coffee business.

    DISCOVER MORE

  • Pods&Caps

    Thanks to the Pods&Caps kit, all Rancilio espresso machines can be used with coffee pods and capsules (according to available systems).

    Rancilio Baby 9 works with coffee pods and capsules (according to available systems).

Dimensions
  • 1040 mm / 40.9 inch
  • 540 mm / 21.2 inch
  • 600 mm / 23.6 inch
  • 100 kg / 220.5 lb
  • 80 mm / 3 inch
Interface
  • Touchscreen 5.7
  • Grouphead display
Brewing technology
  • Steady Brew (SB)

    Rancilio Steady Brew (SB) technology is the evolution of the traditional thermosiphon system and introduces a set of innovative features designed to improve the performance of all single-boiler espresso machines. By keeping the water temperature stable during extraction, Steady Brew guarantees excellent thermal stability, reliability and maximum repeatability, both during busy periods and in low usage conditions. Rancilio Patented Technology.

  • Brass
Water
  • Hot water wand
  • X-Tea

    Baristas can programme water dosages and temperature levels via the interface.
    Rancilio Patented Technology

Steam
  • C-lever

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. Turning it downwards, the valve opens and automatically closes when released.

  • Cool touch steam wand

    The cool touch steam wand is thermally insulated with a double-layered protective coating.

  • iSteam

    The iSteam automatic steam wand features two buttons, both of which can be programmed with the following functions: “Cappuccino”, to heat and froth milk, or “Latte”, to heat only. Rancilio Patented Technology.

Cup warmer
  • Cup warmer

    The cup warmer keeps all espresso and cappuccino cups at the right temperature at all times.

  • Temperature sensor
Power
  • 6000 W
  • 50-60 Hz
  • 220-240/380-415 (3N) V
Boiler
  • 16 liter / 3.5 UK gal
Design
  • Led lights

    White LED lights positioned under the group heads provide excellent illumination for the work area.

  • RGB lights

    The aesthetic RGB lights can be customised with different intensities and colours (Classe 20 only). The functional RGB lights on the group covers (Classe 11, Classe 7 USB) and above the control panel (Classe 9) help the operator to monitor the various states of the machine at a glance.

Green
  • ABM

    ABM is a specific software developed to improve the performance of the machine in conditions of intensive use. When simultaneously brewing espresso, dispensing water and steaming milk, ABM switches on the heating element to pre-empt any drops in pressure under the preset value, thus preventing drops in temperature to ensure constant heating levels.
    Control of the boiler pressure is optimised in the case of the intensive and simultaneous use of multiple group heads. In these cases, in order to prevent the pressure from dropping below a minimum value of 0.5 bar, ABM can stop water from being dispensed until the boiler pressure returns to a suitable level.
    ABM also allows for control of the machine’s power consumption, reducing it to 2/3 of the normal value where power availability is low.
    For espresso machines equipped with the iSteam wand, ABM also improves steam delivery performance by increasing the power of the heating element in the boiler, allowing it to produce more heat and reduce drops in pressure during milk frothing.
    Rancilio Patented Technology

  • Eco Mode

    By managing the different water levels in the boiler, the water-to-steam ratio can be optimised to achieve maximum energy savings. In low usage conditions, the quantity of water in the boiler is reduced, thus increasing the proportion of steam. Working with less water in the boiler allows for lower energy consumption in order to bring it to the ideal temperature. And, at the same time, with more steam and less moisture in the boiler, the performance of the steam wands also improves.

Cleaning & maintenance
  • Easy clean

    Easy Clean manages the cleaning process of the group heads, so it can perform it all automatically. The barista need only start the cycle, and the machine will automatically carry out the washing and rinsing operations. For all models (except the Classe 5 units), Easy Clean also allows you to schedule a daily alarm (3 alarms for the Classe 11 and Classe 20 models) to warn the user of the need for a cleaning cycle, set an optional block on the machine in the event of a cleaning cycle, and view the history of all cleaning cycles performed.

  • Grid System

    The removable cup tray grids are made of a scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.

  • Snap&Share

    Snap&Share is a QR code reader app that allows users to share the technical settings of their espresso machine, keep track of maintenance operations, monitor consumption, and register new products to activate the warranty.

  • USB
Additional Optionals
  • Connect

    Connect is a powerful IoT solution developed by Rancilio Group, to gather and easy analyze all the value relevant data generated by a single coffee machine or an entire fleet. Via a customizable dashboard with widgets, tables and graphs, Connect gives you a ready to use digital toolkit, to monitor key performance parameters in real time and empower your whole coffee business.

    DISCOVER MORE

  • Pods&Caps

    Thanks to the Pods&Caps kit, all Rancilio espresso machines can be used with coffee pods and capsules (according to available systems).

    Rancilio Baby 9 works with coffee pods and capsules (according to available systems).

Dimensions
  • 1280 mm / 50.4 inch
  • 540 mm / 21.2 inch
  • 600 mm / 23.6 inch
  • 115 kg / 253.5 lb
  • 80 mm / 3 inch
Interface
  • Touchscreen 5.7
  • Grouphead display
Brewing technology
  • Steady Brew (SB)

    Rancilio Steady Brew (SB) technology is the evolution of the traditional thermosiphon system and introduces a set of innovative features designed to improve the performance of all single-boiler espresso machines. By keeping the water temperature stable during extraction, Steady Brew guarantees excellent thermal stability, reliability and maximum repeatability, both during busy periods and in low usage conditions. Rancilio Patented Technology.

  • Brass
Water
  • Hot water wand
  • X-Tea

    Baristas can programme water dosages and temperature levels via the interface.
    Rancilio Patented Technology

Steam
  • C-lever

    The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. Turning it downwards, the valve opens and automatically closes when released.

  • Cool touch steam wand

    The cool touch steam wand is thermally insulated with a double-layered protective coating.

  • iSteam

    The iSteam automatic steam wand features two buttons, both of which can be programmed with the following functions: “Cappuccino”, to heat and froth milk, or “Latte”, to heat only. Rancilio Patented Technology.

Cup warmer
  • Cup warmer

    The cup warmer keeps all espresso and cappuccino cups at the right temperature at all times.

  • Temperature sensor
Power
  • 6000 W
  • 50-60 Hz
  • 220-240/380-415 (3N) V
Boiler
  • 22 liter / 4.8 UK gal
Design
  • Led lights

    White LED lights positioned under the group heads provide excellent illumination for the work area.

  • RGB lights

    The aesthetic RGB lights can be customised with different intensities and colours (Classe 20 only). The functional RGB lights on the group covers (Classe 11, Classe 7 USB) and above the control panel (Classe 9) help the operator to monitor the various states of the machine at a glance.

Green
  • ABM

    ABM is a specific software developed to improve the performance of the machine in conditions of intensive use. When simultaneously brewing espresso, dispensing water and steaming milk, ABM switches on the heating element to pre-empt any drops in pressure under the preset value, thus preventing drops in temperature to ensure constant heating levels.
    Control of the boiler pressure is optimised in the case of the intensive and simultaneous use of multiple group heads. In these cases, in order to prevent the pressure from dropping below a minimum value of 0.5 bar, ABM can stop water from being dispensed until the boiler pressure returns to a suitable level.
    ABM also allows for control of the machine’s power consumption, reducing it to 2/3 of the normal value where power availability is low.
    For espresso machines equipped with the iSteam wand, ABM also improves steam delivery performance by increasing the power of the heating element in the boiler, allowing it to produce more heat and reduce drops in pressure during milk frothing.
    Rancilio Patented Technology

  • Eco Mode

    By managing the different water levels in the boiler, the water-to-steam ratio can be optimised to achieve maximum energy savings. In low usage conditions, the quantity of water in the boiler is reduced, thus increasing the proportion of steam. Working with less water in the boiler allows for lower energy consumption in order to bring it to the ideal temperature. And, at the same time, with more steam and less moisture in the boiler, the performance of the steam wands also improves.

Cleaning & maintenance
  • Easy clean

    Easy Clean manages the cleaning process of the group heads, so it can perform it all automatically. The barista need only start the cycle, and the machine will automatically carry out the washing and rinsing operations. For all models (except the Classe 5 units), Easy Clean also allows you to schedule a daily alarm (3 alarms for the Classe 11 and Classe 20 models) to warn the user of the need for a cleaning cycle, set an optional block on the machine in the event of a cleaning cycle, and view the history of all cleaning cycles performed.

  • Grid System

    The removable cup tray grids are made of a scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.

  • Snap&Share

    Snap&Share is a QR code reader app that allows users to share the technical settings of their espresso machine, keep track of maintenance operations, monitor consumption, and register new products to activate the warranty.

  • USB
Additional Optionals
  • Connect

    Connect is a powerful IoT solution developed by Rancilio Group, to gather and easy analyze all the value relevant data generated by a single coffee machine or an entire fleet. Via a customizable dashboard with widgets, tables and graphs, Connect gives you a ready to use digital toolkit, to monitor key performance parameters in real time and empower your whole coffee business.

    DISCOVER MORE

  • Pods&Caps

    Thanks to the Pods&Caps kit, all Rancilio espresso machines can be used with coffee pods and capsules (according to available systems).

    Rancilio Baby 9 works with coffee pods and capsules (according to available systems).
